Videojet® 6230 Thermal Transfer Printer

Videojet® 6230 Thermal Transfer Printer

Thermal Transfer Printer for Flexible Packaging Materials

The Videojet 6230 is a low speed Thermal Transfer Printer that utilizes the latest technology to help reduce flexible packaging coding errors, and improve total cost of ownership (TCO) through a proven and cost-effective solution.

The 6230 Thermal Transfer Printer delivers easy usability with an intuitive tablet-like 5’’ touchscreen controller with CLARiTY™ interface. The simple ribbon path helps to ensure fast changeovers and a more efficient operation.

Code assurance comes as standard in the 6230 Thermal Transfer Printer when using templates created by CLARiSOFT™ or VideojetConnect Design software. These simple code creation tools help reduce operator interactions resulting in fewer user errors and unnecessary product waste and rework.

Available with Bluetooth®* connectivity, the 6230 can also be controlled from an Android phone**, simplifying operator interaction with the printer and production line.

In addition to the features available, the 6230 offers high-quality codes up to speeds of 150 ppm and is an ideal solution for users migrating to a digital solution from analog equipment like hot stamp and roller coders.

* A Bluetooth USB Adapter is required when using the Videojet 6230 App. The Videojet 6230 printer is warranted to work with the recommended Videojet Bluetooth USB Adapter only. **The Videojet 6230 app supports Android OS, Version 4.4.4 (KitKat) or higher. The Android phone is required to allow Bluetooth tethering when using the Videojet 6230 App.

Contact us for New Equipment Sales

Videojet 6230

×

Contact Us

Specs

Specification
Value
Printer ModeIntermittent and Continuous Motion
Print Gap0.5mm (0.020 in)
Maximum Ribbon Length700 meters max
Ribbon WidthsMin: 20mm (0.8 in)
Max: 33mm (1.3 in)
Continuous Mode:
      Maximum Print Area (Width x Length)32mm x 100mm (1.26” x 3.93”)
      Maximum Print Speed 500mm/sec. (19.7 in/sec)
      Minimum Print Speed 40mm/sec.(1.6 in/sec)
Intermittent Mode:
      Maximum Print Area (Width x Length)32mm x 47mm (1.26” x 1.85”)
      Maximum Print Speed 300mm/sec. (11.8 in/sec)
      Minimum Print Speed 50mm/sec (2.0 in/sec)
Bar Code PrintingEAN8, EAN13, UPCA, UPCE and QR codes
Estimated Maximum Throughput (Single Line Code, Continuous Mode)150 packs/min
Standard User InterfaceCLARiTY™ 5.0 inch color QVGA CSTN LCD and touch screen (800 x 480 pixels)
Leader/Follower Capability (Up to 4 Printers Controlled by One User Interface)Up to four Videojet 6230 printers controlled via a single CLARiTY™ control unit
Standard CommunicationUSB memory stick, ethernet, RS232, ASCII and binary communications
Bluetooth ConnectivityWarranted to work with the recommended Videojet Bluetooth USB Adapter only

Benefits

Simple usability

  • Simple change ribbon cassette, with pushbutton lock mechanism, allows for fast and easy ribbon replacement
  • Intuitive tablet-like 5” touchscreen controller with CLARiTY™ interface used on other Videojet printers used in other Videojet technologies

Fits your unique production needs

  • Airless operation removes the need for plant air
  • Offers high-quality codes up to speeds of 150 packs / minute
  • Single design printhead for intermittent or continuous printing
  • Compact design easily integrates into most production lines

Built-in productivity

  • Precise ribbon control with bidirectional stepper motors minimizes gaps between codes and reduces ribbon wastage
  • 700m maximum ribbon length requires fewer ribbon changes versus hot stamp or other competitive TTO systems
  • Simple ribbon path that ensures fast changeovers and a more efficient operation
  • Bluetooth®* connectivity allows operator to control printer from an Android phone**

Code Assurance

  • WYSIWYG print preview allows operators to confirm the correct code is selected
  • Built-in code assurance software helps to reduce operator-induced errors, decreasing unnecessary product waste and rework
  • Real-time clock stamp avoids date errors
  • Benefit from simple code creation with VideojetConnect™ Design or CLARiSOFT™ software

* A Bluetooth USB Adapter is required when using the Videojet 6230 App. The Videojet 6230 printer is warranted to work with the recommended Videojet Bluetooth USB Adapter only. **The Videojet 6230 app supports Android OS, Version 4.4.4 (KitKat) or higher. The Android phone is required to allow Bluetooth tethering when using the Videojet 6230 App.

Applications

Documents

Video

Vidyard Thumbnail
Videojet 6230 Overview

Related Products

Videojet 6230
Videojet 6330
Videojet 6530
Printhead size32mm53mm107mm53mm32mm
Description Our cost-effective TTO printer that provides high-quality codes on flexible film.Our mid-range TTO printer with an airless printhead and iAssure, a built-in tool to check code quality.Our mid-range TTO printer with an airless printhead and iAssure, a built-in tool to check code quality.
Shared specs– Intermittent and continuous motion
– Consistent 0.020” (0.5mm) print gap
– Web browser capable
Ribbon widths20mm – 55mm
(0.8in – 2.2in)
55mm – 110mm
(2.2in – 4.33in)
20mm – 55mm
(0.8in – 2.2in)
20mm – 33mm
(0.8in – 1.3in)
Ribbon grades7 grades
Ribbon lengthsUp to 1200M
Bar code printingEAN 8, EAN 13, UPC-A, UPC-E, Code 39, EAN 128, Code 128, ITF, RSS (including 2D composite codes); others may be available upon requestEAN8, EAN13, UPCA, UPCE and QR codes
Operator interfaceTFT SVGA 800×480 full-color LCD and touch screen, WYSIWYG print preview, full on-board diagnostics, 3 levels of password protection, extensive language supportCLARiTY™ 5.0 inch color QVGA CSTN LCD and touch screen (800 x 480 pixels)
Leader/follower capabilityUp to four of the same Videojet DataFlex® printers controlled via a single CLARiTY™ control unit
