Videojet 1610 Dual Head InkJet Industrial Printers

Videojet 1610 Dual Head InkJet Industrial Printers

5-line CIJ printing Machine best for Batch coding

The Videojet 1610 Dual Head small character inkjet coder extends the benefits of the Videojet 1000 Line printers by offering greater capabilities for demanding production environments. With two printheads, operators have the flexibility to print more content on a given package, to print on two separate locations on a given package, or to print on 2 lanes of a multi-lane application.

Contact us for New Equipment Sales

Videojet 1610DH CIJ Printer

×

Contact Us

Specs

SpecificationValues
Printheads2
InksDye Based
Maximum Lines of Print per Printhead5
Maximum Line Speed(1)293 m/min (960 ft/min)
Environmental ProtectionIP65
Core Life (Maintenance Interval)Up to 12,000 hours
Umbilical Length3 m (9.8 ft) optional 6 m (19.6 ft)
Message Storage Capability250
Smart Cartridge™Included
Plug and Play Printhead ModulesIncluded
USBIncluded
CommunicationsEthernet and RS-232 Serial
Positive Air / CleanFlow™Included
Expanded I/O Ports and Control#
Display (User Interface)LCD with membrane keyboard

# Optional

(1) Based upon single line, 10 characters per inch

Benefits

Speed without compromising quality:

  • Dynamic Calibration™ adjusts jetting parameters automatically to help ensure high quality print
  • Dual printheads enable high speed printing of up to 10 lines of text with single printhead speed performance:
    • Single line max speed = 293 m/min (960 ft/min)
    • Dual line max speed = 146 m/min (480 ft/min)
    • Tri-line max speed = 81 m/min (265 ft/min)

Engineered for extended runs; Uptime Advantage via:

  • CleanFlow™ technology resists ink buildup that can cause ordinary inkjet printers to shut down
  • Long run time between preventive maintenance; up to 12,000 hour core life
  • Internal pump means no external air, minimizing potential for contaminants to enter ink stream
  • Auto cleaning printhead for fast start-ups, even after extended shutdowns

No mess, no waste fluid delivery:

  • Make-up consumption as low as 2.4 ml/hour
  • Smart Cartridge™ fluid delivery system to virtually eliminate spills and help ensure the correct fluids are being used

Simple Usability via Videojet standard CIJ interface:

  • Bright display with WYSIWYG and function keys for easy operation
  • User levels to separate operation from installation and maintenance
  • Prompted user fields to help reduce coding errors

Applications
